3 Phase Coiled Type 2 To Type 2 IEC 62196 EV Charging Cable

  • 16A 480V 3 Phase 11kW Coiled EV Charging Cable Type 2 To Type 2 IEC 62196

  • Hpconnect

Product Description

16A 480V 3 Phase 11kW Coiled EV Charging Cable Type 2 To Type 2 IEC 62196

The spiral charging cable offered here is three-phase with 16 amps and can therefore conduct maximum charging power of 11 kilowatts . It has a cable length of about 4 to 5 meters (due to the spiral shape only approximate information depending on the pull on the spiral cable). This charging cable is CE certified . The insulation is made of TPU (thermoplastic polyurethane) . This makes the insulation thinner and lighter while maintaining optimum insulation. It arrives in a secure and custom-fit outer carton.

Type 2 charging cable suitable for all e-cars and plug-in hybrids in a special spiral shape for charging without contamination of the charging cable. The spiral shape connects your charging cable to the charging station and the cable tension avoids contact with the ground. The charging cable hangs in the air and is therefore less worn and, above all, not dirty.

The coiled design of the Type 2 to Type 2 IEC 62196 EV charging cable makes it convenient to use in a variety of charging scenarios, such as public charging stations or home charging setups. The cable is typically made from durable and weather-resistant materials to withstand the rigors of daily use, and features safety features such as overcurrent protection and a locking mechanism to ensure a secure connection during charging.

Why do I need a spiral charging cable to charge my electric car or PHEV?

Of course, you park your e-car at the charging station so that the distance from the charging point to your vehicle connection is as short as possible. The standard charging cable, which is often five meters long and smooth, is actually a bit oversized for the distance and the rest of the charging cable lies on the ground in the dirt or, worse, in a puddle. For this we now have the new spiral charging cable in our range. Due to the spiral shape, the charging cable does not lie on the ground, but hangs in the air between the charging station and the electric car and is therefore neither dirty nor damaged.


ev charger cable

ev charger cable


ev charger cable


           1.Lightning protection

           2.Over-voltage protection

           3.Leakage protection

           4.Over-load protection

           5.Waterproof IP65(operating state)

ev charger cableev charger cable

Product  Name 16A 480V 3 Phase 11kW Coiled EV Charging Cable Type 2 To Type 2 IEC 62196
Length 5m or customized length
Rated current 16A - 480V - 11kW, Three-phase
Operation Volatge 480V
Insulation resistance more than 500M Ohm(DC500V)
Contact resistance 0.5m Ohm max
Terminal temperature rise less than 50K
Withstand voltage 2000V
Mechanical life no-load plug in/out  more than 10000 times
Coupled insertion force 45N~100N
Impact of external force can afford 1M drop
Operating Temperature -30~+50ºC
Case material thermoplastic, flame retardant grade UL94 V-0
Termminal Copper alloy , silver plating
Features Easy: Charge at home, at work, or anywhere with the  socket. No installation is required, just an intuitive pairing process. Plug  and charge, wherever you are;
Safe: Protecting Earthing detection;
Designed for electric cars using the IEC 62196  standard. The  precision engineering of the internal circuit board allows automatic  detection and correction of any problems during charging, including any  issues with minimal, unstable, or excessive voltage, current, frequency,  earth leakage, and temperature even during lightning and electrical storms.


Q1: Rated current

A: 16A/32A


Q2: Maximum charging power

A: 3.5KW/7KW/11KW/22KW

Q3: Delivery time

A: Sample time is within 3 days.

    Bulk order is 7-10 working days.

Q4: Warranty

A: 1 year.

Q5. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 7-10 days to arrive. Airline and sea shipping also optional.

Q6. Can I have a sample order for EV charging cables?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q7. Is it OK to print my logo on the products?

A: Yes. Please inform us formally before our production.

Q8: Do you offer guarantee for the products?

A: Yes, we offer 2 years warranty to our products.

Q9: How to deal with the faulty?

A: 1)Our products are produced in strict quality control system and the defective rate will be less than 0.5%.

2)During the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
